FAST 307030 Fuel Pressure Regulator 30-70

FAST 307030 Fuel Pressure Regulator 30-70

Brand : FAST

MPN : 307030

AlternatePartNumber : fst307030

UPC : 036584211877

Product Department : Fuel Delivery

Product Category : Fuel Pressure Regulators

BoxQuantity : 1

Length : 4.0 inches

Width : 2.75 inches

Height : 2.0 inches

Weight : 1.75 lbs

Prop65 : Yes

Not CARB Legal

The FAST Adjustable Fuel Pressure Regulator is a premium CNC billet regulator designed to exact specifications by our engineers. The unit features twin -6 SAE feed side ports and one -6 SAE return port on the bottom. The fully adjustable unit is vacuum referenced and utilizes a hex adjustment stud with jam nut. The unit has a 1/8 NPT gauge port, as well. The regulator is a kit, including the unit, mounting bracket, 1/8 NPT plug and 1/8 NPT to 3/16" barb. The regulator can be used with a single feed (plug second feed) or with dual feeds. Requires the purchase of port fittings separately (all three ports are -6 SAE o-ring type).
