Snow Performance SNF-52200X fits Chevrolet Camaro 5th Gen/fits Cadillac CTS-V 2n

Snow Performance SNF-52200X Snow Performance fits Chevrolet Camaro 5th Gen/fits Cadillac CTS-V 2nd Gen Xtreme Version Fuel Hat (3 Pump)

Brand : Snow Performance

MPN : SNF-52200X

AlternatePartNumber : snoSNF-52200X

UPC : 653374984140

Product Department : Fuel Delivery

Product Category : Fuel Pumps

BoxQuantity : 1

Length : 15.5 inches

Width : 8.5 inches

Height : 8.5 inches

Weight : 15.0 lbs

Prop65 : Yes

Not CARB Legal

To meet your specific vehicle's fuel demands, these pump assemblies are configurable with a combination of 2 or 3 fuel pumps. No knock-off pumps here. Get OE reliability with genuine TI Automotive (Walbro) fuel pumps in your choice of flow rates (450LPH or 470LPH). These fuel pumps are designed for a return-style installation only. Do not attempt to run these pumps in a returnless application. These pumps are compatible with 100% Gasoline, 100% Ethanol or any blend of Gasoline and Ethanol (E10, E85, E98 for example). These pumps are NOT compatible with methanol. For street-driven applications, it can be beneficial to combine a smaller fuel pump along with one or two larger fuel pumps. This allows you to street drive on the smaller fuel pump which has a lower amp draw and does not generate as much heat. Once you get into boost, the larger pumps can be activated to support your high horsepower needs. The easiest way to do this is to use a Snow Performance Boost activated pressure switch (part # SNO-81014) and a Snow Performance Multi-Pump Relay Module (part # SNF-20003). Available pump configurations are shown below: 2 Pump Street able Configuration (one 450lph pump and one 470lph pump). This configuration is capable of supporting 1000+ rwhp on e85 and 1300+ on gasoline. -Current Selection 3 Pump Street able Configuration (One 450lph pump and Two 470lph pumps)- This configuration is capable of supporting 1500+ rwhp on e85 and up to 2000 rwhp on gasoline. This configuration draws 10-12% less current than the ?Race 3 pump version. 3 Pump Race Configuration (Three 470lph pumps). This configuration is capable of supporting 1600+ rwhp on e85 and up to 2100 rwhp on gasoline. This configuration is designed for max effort/flow.

This Part Fits:

Year	Make	Model	Submodel
2009-2015	Cadillac	CTS	V
2010-2015	Chevrolet	Camaro	LS
2010-2015	Chevrolet	Camaro	LT
2010-2015	Chevrolet	Camaro	SS
2014-2015	Chevrolet	Camaro	Z/28
2012-2015	Chevrolet	Camaro	ZL1
