FOX 883-06-233 10-14 fits Ford Raptor 3.0 Series Front Coilover w/ Internal Bypass - 2in Lift

FOX 883-06-233 10-14 fits Ford Raptor 3.0 Series Front Coilover w/ Internal Bypass - 2in Lift

Brand : FOX

MPN : 883-06-233

AlternatePartNumber : fox883-06-233

Product Department : Suspension

Product Category : Coilovers

BoxQuantity : 1

Length : 40.6 inches

Width : 18.9 inches

Height : 10.8 inches

Weight : 92.8 lbs

Prop65 : Yes

Uncompromised performance through FOX’s patented internal bypass technology delivers the feel of near-endless suspension travel. Exclusive internal bypass technology allows oil to flow around the piston at some points of the stroke – while creating humongous pressure at other points – supporting the vehicle like no other product can.Floating through terrain is accomplished with FOX’s ride zone – combining a race-developed shock piston, internal bypass and Dual Speed Compression adjustment – allowing fine tuning for weight, terrain and speed.Dominate any terrain with the brute strength of 3- and 2.5-inch aluminum bodies, cactus cooler reservoirs and 7/8” shafts with redundant seals, all proven in the harshest of environments under the toughest of conditions.
Technical Drawing
Installation Instructions


This Part Fits:

Year	Make	Model	Submodel
2010-2014	Ford	F-150	SVT Raptor
