Edelbrock 614669 Cylinder Head BBC BV3 Pro Port Hipd 11 Intake Valve

Edelbrock 614669 Cylinder Head BBC BV3 Pro Port Hipd 11 Intake Valve

Brand : Edelbrock

MPN : 614669

AlternatePartNumber : ede614669

UPC : 85347996483

Product Department : Engine Components

Product Category : Heads

BoxQuantity : 1

Length : 26.5 inches

Width : 12.13 inches

Height : 9.0 inches

Weight : 70.0 lbs

Prop65 : Yes

Not CARB Legal

The Edelbrock 614669 Big Block Chevy Big Victor III 11deg Pro-Port Cylinder head is designed specifically for the professional cylinder head porter and engine builder. Like the other Edelbrock Cylinder head, The Pro-Port cylinder head is also cast in the USA at the state-of-the-art Edelbrock Foundry with extra-thick walls to allow for custom CNC porting. In most cases, seats and manganese-bronze valve guides are included, but not installed. Please note: This head can not be used without professional head preparation. Pro-Port RAW Features Include: - Unported versions of Edelbrock race-winning Victor Series CNC head for the professional cylinder head porter and engine builder - The Pro-Port cylinder head is cast in the USA at the state-of-the-art Edelbrock Foundry with extra-thick walls to allow for custom CNC porting - The only head designed specifically to accommodate almost any CNC port shape, size or location - Offers enough wall thickness for CNC machining to various port dimensions - In most cases seats and manganese-bronze valve guides are included - Some of the Edelbrock Pro-Port Raw Head Feature Our Special Hot Isostatic Pressing or HIP Process.
