Aeromotive 13202 A2000 Carbureted Bypass Regulator - 4-Port

Aeromotive 13202 Aeromotive A2000 Carbureted Bypass Regulator - 4-Port

Brand : Aeromotive

MPN : 13202

AlternatePartNumber : aer13202

UPC : 684980000108

Product Department : Fuel Delivery

Product Category : Fuel Pressure Regulators

BoxQuantity : 1

Length : 8.1 inches

Width : 5.0 inches

Height : 4.0 inches

Weight : 1.6 lbs

Prop65 : Yes

Not CARB Legal

Dynamic flow and rock steady pressure make this regulator perfect for naturally aspirated or carbureted blow-through applications. The A2000 Bypass Regulator provides unmatched boost reference and high flow capacity. Compatible with any high volume electric or mechanical fuel pump. Adjustable from 2-20 PSI. Bypass design provides the ultimate, dynamic fuel delivery system. (Requires AN-10 return line.) Fuel pressure rises on a 1:1 ratio when referencing boost. ORB-10 inlet and return ports. P/N 13202 provides (4) ORB-08 outlet ports.?Note: High pressure, boost reference applications require high volume, high pressure fuel pumps. EFI capable, electric or mechanical pumps like the Aeromotive Pro-Series (P/N 11102), Eliminator (P/N 11104), or Belt Drive Fuel Pump (P/N 11105) are strongly recommended.
