Aeromotive 13204 A1000 Carbureted Bypass Regulator - 2-Port

Name: Aeromotive 13204 A1000 Carbureted Bypass Regulator - 2-Port
Brand: Aeromotive
SKU: AER13204
Price: 231.95 USD
Availability: InStock

Aeromotive

Manufacturing Part Number (MPN)

13204

Price:

$231.95

Stock:

Only 3 units left

Quantity:

Economy delivery - on or before 7 business days - 17th

Standard delivery - on or before 5 business days

Expedited - on or before 3 day

Second Day - on or before 2 days

Next Day -on or before 1 day

Aeromotive 13204 Aeromotive A1000 Carbureted Bypass Regulator - 2-Port

Brand : Aeromotive

MPN : 13204

AlternatePartNumber : aer13204

UPC : 684980000320

Product Department : Fuel Delivery

Product Category : Fuel Pressure Regulators

BoxQuantity : 1

Length : 7.1 inches

Width : 5.0 inches

Height : 3.0 inches

Weight : 0.9 lbs

Prop65 : Yes

Not CARB Legal

The A1000 Bypass Regulator was designed for use with our A1000 Fuel Pump or similar style EFI pumps in a carbureted application. This regulator is perfect for naturally aspirated or ?blow-through? supercharged engines. Base fuel pressure adjustable from 3-15 PSI. (1) ORB-10 inlet port and (1) ORB-08 return port. P/N 13204 provides (2) ORB-06 outlet ports and 1/8' NPT gauge port. Fuel pressure rises on a 1:1 ratio when referencing boost. Bypass design provides the ultimate, dynamic fuel delivery system. Ideal for converting from fuel injection to carburetion using the stock, in-tank pump. EFI conversions will require a larger-than-stock return line for proper low pressure control.?Note: Requires AN-08 return line from bottom of regulator back to top of the tank.
